Current density is inversely proportional to it, and power dissipation depends on current density. Saturation (which must be avoided for the transformer to remain linear) depends on flux density. Flux density is proportional to applied voltage, and inverse to area and frequency. See also the toroid inductor online calculator which is helpful to build your own toroid inductor.There are two facts necessary to the design of a transformer: So in this way you can make your own RF transformer using toroid for impedance matching. This RF transformer then matches the 50Ohm source impedance with 4Ohm load impedance which is the base impedance.
So we need 47 turns for primary winding and 13 turns for secondary winding on T-50-2 toroid core to make the RF transformation for impedance matching. The number of windings and the impedance is related by the following equation. The impedance at the primary and secondary are Zp and Zs. The number of turns of primary winding and the secondary winding are Np and Ns respectively. In this the toroid transformer is connected with its primary winding on the signal source side and the secondary winding connected to the base of an RF amplifier transistor. Then the turns are wound on the toroid core to build the RF transformerĬonsider the following circuit. Then using the primary number of turns and the turn ratio we calculate the number of the secondary winding. By selecting the toroid core we will know the inductance factor AL and together with the primary inductance knowledge we will know the number of turns for the primary winding.
Once we know the primary winding inductance we next select toroid core based on frequency of operation and suitable size for winding the core. Then we estimate the inductive reactance at the primary side(or secondary side) for given frequency and calculate the inductance for the primary winding. First we calculate the turn ratio using the knowledge of source and load impedance to be matched. The process of making RF transformer using toroid core is explained briefly. For calculating the number of turns we need to know the source and load impedances and frequency range over which the circuit is operated.
To build the toroid RF transformer we need the number of turns for the primary and secondary and select a toroid core.
